  • single Channel Wireless Receiver

HR-30S

single Channel Wireless Receiver
Inquire Now Next Product

HR-30S

Product Description Details Technical Specifications

Product Description

HR-30S true diversity wireless microphone system is a wide bandwidth true diversity wireless audio system that designed for the large-scale live show.Powerful function, reliable performance, can get the best effect in different kinds of complicated professional performance.

Optional

Microphone base

UD-223

UD-223

Gooseneck microphone

Connection diagram

Connection diagram

Details

1

2

3

4

5

1

2

3

4

5

Technical Specifications

Main Frame Size: ½ EIA standard 1U

Carrier Frequency Rang: 521.25MHz-936.85MHz

Receiving Channel: Single Channel

Receiving Mode: True Diversity

Frequency Reliability: ±0.005%(-10~50℃)

Bandwidth: 32MHz

Audio output jack: XLR balanced socket and Φ6.3mm unbalanced socket

Antenna socket type: BNC

Control cable: 4P telephone line connect to the U485, U485 USB connect to computer.

Operationg Distance: 80M typical(in open space)

Oscillation: PLL synthesized

Sensitivity: 5dBμV, S/N>60dB at 25KHz deviation

Max. Deviation: ±45KHz

Power Supply: DC-12V / 1A

Dimension(mm)206(w)×206(D)×43(H)

Weight: Approximately 1.0kg
