mage sensor: 1/2.8 inch STARVIS CMOS
Effective pixel: 3.5 million pixels
Signal system HD: 1080p60/501080p30/251080i60/50720p60/50
Signal system: 10PAL/NTSC
Lens: 20x optical zoom f=4.7mm (wide angle end)~94.0mm (far end)
Horizontal angle of view: 58.7 ° (wide angle end)~3.2 ° (far end)
Aggregation mode: automatic/manual
Minimum lighting: 0.1Lux
Shutter speed gain: 1/1 ～ 1/10000S
White balance: automatic/manual/indoor/outdoor
Image effect: color/black and white/electronic flip
S/N ratio: above 50dB
Horizontal sway: 355 ° (maximum speed 80 °/s)
Pitch and sway: - 30 ° to 90 ° (maximum speed 60 °/s)
Preset position: 9 remote controls and up to 200 keyboards
Video output HD: HDMI, 3G-SDI, USB 2.0, RJ-45
Audio input: 3.5mm LINE-IN
Power requirement: 12V DC (10.8~13.0V DC)
Operating temperature: 0 ℃~40 ℃
Storage temperature: - 20 ℃~60 ℃
Size: (length) 170 × (Width) 151 × (Height) 190mm
Power consumption: maximum 12W (at DC 12V)
Weight: 1310g
Product color: black
Control protocol：SONY VISCA、PELCO P/D
Control mode：RS-232C, RS-422/485, USB control
