Product Description
Podcast+is a audio mixer specifically designed for live streaming app.It integrates live streaming application functions such as mixing, sound effects,etc.It can be connected to two mobile phones or computers simultaneously and transmit audio to live streaming devices through digital audio technology.Lightweight and easy to carry,the panel layout is simple, and the functional differentiation is clear and easy to understand. Equipped with Type-C interface to charge, which can realize charging while broadcasting, eliminating the trouble of live broadcast battery life.Podacast+ is suitable for mobile phones, computers, etc.
Performance Introduction
Simulate On-site Reverberation
Podcast+ has 16 simulated live reverb effects internally, which can be selected according to the live content to enhance the atmosphere of the live broadcast.
48v phantom power switch
It can provide power for microphone port for live broadcast condenser microphone
Internal Play Switch
When the Internal Play switch is turned on, the input audio from the Type-C will not be sent back to the Type-C output, eliminating echo issues.
MIC PRIOR Switch(Ducking)
When the MIC PRIOR switch is turned on, it automatically reduces the volume of background music and sound effects when there is audio input from the microphone
Custom Sound Effects
Comes with 9 built-in sound effects, which can be replaced via USB.
Intelligent Noise Reduction
When the noise reduction switch is turned on, it reduces the ambient noise picked up by the microphone.
Technical Specifications
Sample Rates:24 - bit, 48 KHz
Frequency Response:20Hz to 20 KHz
System Delay:1.5ms
T.H.D:<0.05%
Input Crosstalk:>65dB @ 1KHz(Adjacent Channels)
S/N Ratio:90dB single channel - fader max (A-weighted)
Dynamic Range:90dB single channel - fader max (A-weighted)
Common Mode Rejection Ratio:>60dB @ 1 KHz
MIC Impedance:3kΩ(XLR Balance);6.6kΩ(1/4)
MIC Gain: 0 to 45 dB(XLR)
Power Supply:DC 5V(1A)
Dimensions(mm):260(L)×230(H)×89(D)
Weight:1.5kg
Support
Operation manual
