WAM-432

Intelligent True Diversity Wireless Mixing System

The WAM-432 fully automatic intelligent wireless mixer is a new generation of products designed with the strong R & D capabilities of Likar. It uses a high - performance microcomputer processor as the core. With a professional and novel appearance design, it comprehensively combines digital control technology, advanced audio processing technology and network technology, enabling intelligent control and fully automatic operation.

Inquire Now

WAM-432

Functional Features Technical Specifications Components FAQ

Functional Features

IR Infrared Frequency Synchronization

It features an [IR] infrared automatic frequency synchronization function. After entering the menu and selecting "IR Infrared Frequency Synchronization", the transmitter can immediately and accurately lock onto the operating frequency point of the receiver.

Flexible configuration

The configuration encoder and the quadruple touch switch are flexibly combined to operate various functions and parameter settings. The 128 × 64OLED display screen can display various information of the receiver and transmitter at the same time

vast expansion

One AMC-20 can simultaneously connect five WAM-432 wireless audio mixers to form a video conference for up to 20 people.

[AFS] Automatic Frequency Search

It has the function of [AFS] automatic search channel. After entering the menu and selecting the automatic frequency search function, it will automatically search and lock on an undisturbed working channel.

Technical Specifications

Receiving method: True diversity reception Receiving channels: Four channels Frequency range: 521.25MHz - 936.85MHz Frequency stability: 0.005% Modulation method: FM Maximum deviation: ±45KHz Tuning: 32KHz Receiving sensitivity: When the deviation is equal to 25KHz and the input is 5dBuV, S/N > 60dB Number of stackable units: 5 units (for simultaneous use) Frequency response: 65Hz - 16KHz, 150Hz - 16KHz (low - cut) Total harmonic distortion: ≤0.7% @ 1KHz Dynamic range: > 95dB Signal - to - noise ratio (A - weighted): > 92dB Audio output: XLR Cannon socket Data connection: RJ11 Communication port: RS - 232 Power supply: DC 12V/1A Operating current: 700mA Chassis specification: EIA standard 1U Dimensions (mm): 410 (W) × 43 (H) × 206 (D) Weight: Approximately 2.5kg

Components
